| Number of Ports | 1 | Series | TM-P |
|---|---|---|---|
| Operating Temperature | -25to60 ℃ | Contact Resistance | 230mΩ Max. |
| Rated Voltage (AC) | AC125V | Rated Current | 0.5A |
| Housing Color | Clear | Contact Plating | Gold |
| Wire Termination Method | Piercing | Number of Positions | 8 |
| Cable Outer Diameter | 8.8mm | Wire Insulation Diameter | 0.9to1mm |
| Recommended Wire Size (AWG) | AWG26 | Connector Type | Plug |
| 品牌 | hirose/广濑 | Opening Size | 8 |
| Generic Type | RJ-45 | Industry Standard | FCC |
| Pick-up Tape | No | Plating Thickness | 1.27µm |
| Recommended Wire Type | Non-shieldedcable | Mating/Unmating Cycles | 200 |
| Product Mass | 1.71g | Minimum Order Quantity | 1PCS |
| Packaging Type | Bag | Connector Length | 11.7mm |
| Connector Width | 22.5mm | ||
